Basic detector workflow for Lacey grids
Revision as of 16:11, 13 February 2017 by Daniel Castaño (talk | contribs)
This is the default detection workflow for the Hole Picker, suitable for Lacey grids. Its execution GUI comprises 8 steps.
Contents
Algorithmic steps
Sobel filtering
Produces and image that enhances the boundaries between holes and carbon.
Boundary dilation
Uses the dilation morphological operator to widen the found boundaries.
Binarization
Size based roi selection
Thinning of selected points
Point reordering
Workflow GUI
The GUI allows for independent execution of each step.
Support tools
With the Visualization menu in the workflow GUI you can launch a view that represents the result of all the steps in the workflow, updating the results after each execution.
File:BasicLaceySupportingGUIGlobal.png Steps in the basic lacey workflow |
